MIL-M-82433A(OS)
Table II
Shock Schedule
Number
Peak Magnitude Minimum Duration Acceleration
of
Condition
Impact
(see 6.3.2)
Direction*
ms
(g's)
60
±10%
8.0 to 10.0
X,Y or Z
Ready nonoperating
9
Axis
45
±10%
18.0 to 20.0
Z Axis-
Ready
3
Forward
0.5 to 1.5
X, Y or Z
6
85
±10%
Axi 6
300
±10%
Z Axis-Aft
0.5 to 1.5
3
*See Figure 1 for axes of' motor.
3.4.3 Acceleration. The motor shall withstand the accelerations spec-
ified in Table 111 (see Figure 1).
Table III
Acceleration Schedule
Magnitude
Acceleration
Condition
(g's)
Direction
see 6.3.2)
25
±10%
Z Axis - Forward
Ready
35
±10%
Z Axis -Aft
3.4.4 Temperature. The motor shall be capable of withstanding the tem-
peratures for the following specified conditions:
3.4.4.1 Nonoperating and ready nonoperating. The motor shall be cap- .
able of meeting the performance requirements subsequent to withstanding,
in the nonoperating condition, environmental temperatures between -45°F
and +140°F. Temperature is defined in 6.3.5
9
