MIL-C-82632A(OS)
28 November 1983
Superseding
MIL-C-82632(OS)
3 September 1976
MILITARY SPECIFICATION
CONNECTOR KIT, SPLICE, SINGLE WIRE
This speciflcation Is approved for use by the Naval Sea
Systems Command, Department of the Navy, and is available
for use by all Departments and Agencies of the Department
of Defense.
1.
SCOPE
1.1 Scope. This specification establishes the minimum requirements for the
procurement of a single wire splice connector, DL 5545977. The connector joins
the shipboard guidance wire to the torpedo guidance wire and maintains electrical
continuity in seawater to a pressure of 1500 psig. The connector will accept
wire sizes from AWG 25 to AWG 23 and is of one type and class.
2. APPLICABLE DOCUMENTS
2.1 Government documents.
.
2.1.1 Specifications and standards. Unless otherwise specified (see 6.2), the
following specifications and standards of the Issue listed in that issue of the
Department of Defense Index of Specifications and Standards (DoDISS) specified In
the solicitation, form a part of this specification to the extent specified heretin.
SPECIFICATIONS
FEDERAL
PPP-B-636
Boxes, Shipping, Fiberboard
PPP-T-76
Tape, Preasure-Sensitive, Adhesive Paper
(for Carton Sealing)
MILITARY
Preservation-Packaging, Methods of
MIL-W-82599
Wire, Insulated, Hard Drawn Alloy of Copper-
Cadmium, No. 23 AWG
